City Of Rain
Senior Member
Pretty soon, you won't be able to see the mountain.
The Smithe | 87.47m | 27s | Boffo Developments | GBL Architects
- Thread starter Roundabout
- Start date
officedweller
Senior Member
Action shots by me Saturday, Nov 16th.
I've seen them stop traffic on Smithe while hoisting the forms,
but not this time.
I've seen them stop traffic on Smithe while hoisting the forms,
but not this time.
officedweller
Senior Member
Pic by me today:
officedweller
Senior Member
First window wall is up today.
They have built a short concrete (?) sill on which the window wall sits.
Not sure why that is, but presumably for weather protection from pooling water since the window wall is setback from the slab edge.
The window wall is also set between two steel stud framed walls, so there is the delay in framing each opening.
Pic by me today.
From yesterday's pic - showing the sill.
I just realized that they cut back the framed walls that they had built.
Pic below from Nov 5th where the walls go almost to the slab edge.
The current state is about a foot back from the slab edge
(you can see the recesses in the underside of the slab for venting)
They have built a short concrete (?) sill on which the window wall sits.
Not sure why that is, but presumably for weather protection from pooling water since the window wall is setback from the slab edge.
The window wall is also set between two steel stud framed walls, so there is the delay in framing each opening.
Pic by me today.
From yesterday's pic - showing the sill.
I just realized that they cut back the framed walls that they had built.
Pic below from Nov 5th where the walls go almost to the slab edge.
The current state is about a foot back from the slab edge
(you can see the recesses in the underside of the slab for venting)
officedweller;8738910 said:Pics by me [Nov 5th]:
officedweller
Senior Member
PS - the ledges match the rendering
(although the rendering shows the transfer slab with no ledge, as-built, it has a ledge)
Mullion configuration is different though.
(although the rendering shows the transfer slab with no ledge, as-built, it has a ledge)
Mullion configuration is different though.
officedweller;8265460 said:
officedweller
Senior Member
Pic by me Thurs Nov 21st:
officedweller
Senior Member
Pics by me today.
officedweller
Senior Member
Pics by me today - west side window wall installed.
officedweller
Senior Member
Pics by me today:
Fire sprinkler pipes are in on the office floors.
Looks like they'll have bare ceilings (sprinkler heads point up).
Note the orange marks on the ceiling marking the columns above.
Fire sprinkler pipes are in on the office floors.
Looks like they'll have bare ceilings (sprinkler heads point up).
Note the orange marks on the ceiling marking the columns above.
officedweller
Senior Member
Pic by me today.
Bye bye view of Harbour Centre...
Not sure if The Post will poke out above, probably not.
Bye bye view of Harbour Centre...
Not sure if The Post will poke out above, probably not.
City Of Rain
Senior Member
Glad to see the darker cladding instead of the usual light blueish green color.
officedweller
Senior Member
Pics by me January 4th:
Glass has been installed past the angle on the Smithe side.
*************
Pics by me yesterday, January 8th:
*************
Moving FAST!
Pics by me today January 9th - one day later.
Glass has been installed past the angle on the Smithe side.
*************
Pics by me yesterday, January 8th:
*************
Moving FAST!
Pics by me today January 9th - one day later.
City Of Rain
Senior Member
Looks like 4 more floors to go.
officedweller
Senior Member
officedweller
Senior Member
Pics by me yesterday.
Yes, they were moving forms in those wind gusts.
They've moved some tarps, so you can see the transfer slab for the penthouse floors.
This rendering shows a setback for the top 3 floors.
Another render from below seems to only show 2 penthouse floors, but this one shows 3 (and 3 penthouse floors makes 26).
Yes, they were moving forms in those wind gusts.
They've moved some tarps, so you can see the transfer slab for the penthouse floors.
This rendering shows a setback for the top 3 floors.
Another render from below seems to only show 2 penthouse floors, but this one shows 3 (and 3 penthouse floors makes 26).
Last edited:
